Description
| AIRPLANE | Information Table | ||
|---|---|---|---|
| RC World product configuration table (c) 2020 | |||
| Type | LARGE SCALE IMAC/3D | ||
| Wingspan | 2.60m | ||
| Length | 2.36m | ||
| Scale | 33% | ||
| Channels | 5ch | ||
| Power setup | 85-120cc Petrol | ||
| Undercarriage | Alloy | ||
| Weight | 11.5kg | ||
| Wing loading | 133.3dm2 | ||
| notes | |||
Kit includes: Using a new composite technology, we were able to come up with extremely light airplane. And if you use a single cylinder 85ccm engine, you will get an incredible power to weight ratio!! What we would like to point out?? A high prefabrication of this ARF and it’s perfect quality!- canopy and cowl are installed- alu landing gear ready to be attached- rudder servo tray glued in- bulkheads installed- fuel and smoke tank holders glued in- wings servo bays installed- predrilled location for control horns an all surface- predrill plates for different engines included- and of course a huge area in fuselage when canopy latch is removed! Simply fast and effective work !!! By our estimates, time needed to complete this airplane is around 20 – 25 hours!! That’s not too bad, right? Parts description:1 – Fuselage: vacuum sandwich with all bulk heads installed, including c/f inside canopy frame2 – Wings: vacuum sandwich. Alu wing tube 40mm, each panel needs 2 servos( JR 8711).3 – Elevators: vacuum sandwich. Can be taken apart if needed. Hinge wire is a brass tubing. Each half has one mount for JR 8711. Two alu tubes 10/1mm.4 – Rudder: vacuum sandwich. Hinge wire is a brass tube, removable on the bottom, if rudder needs to be removed for transportation.5 – Canopy hatch: Alu/titanium look – comes with every kit, standard equipment. Carbon fiber – must be ordered extra. Glued into canopy frame. ..NOT RECOMMENDED TO BE USED WITH 2.4Ghz!!!!!!!!Clear ( transparent) – must be ordered extra. Glued into canopy frame. Canopy frame is fitted on to fuselage from factory. Only two M4mm screws and two wooden dowels are used.6 – Cowl: f/g part. Fitted to the fuselage and attached using 8 M4 screws. Any 80 – 120ccm size engine will fit in without any problems.7 – Landing gear: alu, with all the holes predrilled. Wheel pants are f/g. We have come up with original paint schemes for this plane.
“
